Pylontech Force H3X 12kW 3-Phase Hybrid Inverter with Energy Meter

The Pylontech Force H3X 12kW is a compact three-phase hybrid inverter designed for residential solar installations combined with battery storage. It supports both grid-connected and off-grid (backup) operation with a nominal backup power of 10 kVA and ultra-fast switching time of ≤10 ms.

The inverter features three independent MPPT trackers with integrated energy metering and three current transformers (CTs) for system monitoring. Communication is via WiFi, LAN, and Bluetooth for seamless integration with the Force H3X hybrid system. Maximum input voltage is 1000 V DC, with a rated MPP voltage range of 200–850 V and 30 A short-circuit current per MPPT.

Built-in protections include anti-islanding, insulation resistance detection, residual current monitoring, output overcurrent and overvoltage protection, and DC switch with reverse polarity protection. The unit is naturally cooled, operates across −10 to +55 °C, and is rated IP65 for outdoor or sheltered indoor installation.
