Pylontech Force H3X 5kW Single Phase Hybrid Inverter

The Pylontech Force H3X 5kW is a single-phase hybrid inverter designed for residential solar and battery storage systems. It combines grid-connected and off-grid (backup) operation in one compact unit, with a maximum AC apparent power of 5 kVA and switchover time of ≤10 ms.

The inverter features 2 MPPT inputs with an 80–550 V rated voltage range and supports up to 21.7 A continuous current to grid. It integrates a battery management system, energy meter, and CT sensor for comprehensive system monitoring. Communication is enabled via WiFi, LAN, and Bluetooth for real-time configuration and remote control.

Built with transformerless topology and natural cooling, it operates across a temperature range of −10 to +55 °C. Maximum efficiency is 97%, with European efficiency of 97.5%. The unit measures 540 × 495 × 350 mm and weighs 38 kg.
